Page 47
3
4
SCALE 1 : 4
6
4
DETAIL A
5
3
TO
TO TRANSMISSION
SUPPLIED PLUG
TO CUSTOMER
TO TOP
CABLE HOLE
1
2
7
8
10
19
14
16
15
15
18
17
20
JACKSHAFT
ROTATE BOX 180
ITEM
PART
NO.
QTY.
DESCRIPTION
1
2600118
1
Motor, 20hp Baldor
2
6010996
2
Electric Motor Spacer Plate
3
2900058
8
Flat Washer, 1/2" SAE
4
2900084
8
Lock Washer, 1/2" Split
5
2900139
4
Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
6
2900025
4
Cap Screw, Hex Hd., 1/2-13 x 1-1/4"
7
2503854
1
QD Bushing, SK x 1-5/8", W/Fasteners
8
2500866
1
Sheave, 3V-6.90-8 Groove QD/SK
9
2500678
4
Vibration Isolator, 3/8-16
10
2800653
1
Soft Start Control Box
ITEM
PART
NO.
QTY.
DESCRIPTION
11
2900014
8
Flat Washer, 3/8" SAE
12
2900006
8
Lock Washer, 3/8" Split
13
2900033
8
Hex Nut, 3/8-16
14
2800339
1
Cord Grip, To 7/8", 90 Deg.
15
2800193
2
Lock Nut, 1"
16
6010994
1
Cable, 6 Gage, 4 Wire, 24"
17
2802056
2
Washer, Reducer, 2.62 - 1.36"
18
2800312
1
Connector, 1" Sealtite Elbow
19
2500793
4
V-Belt, 3VX425
20
2500037
1
V-Belt, 3VX375
6043462 MOTOR & SOFT START ASSEMBLY, 20HP
9
11
12
SCALE 1 : 4
DETAIL B
13
