AVerMedia Technologies AVERDIGI EB3004 MD User Manual
Page 32
28
OSD MENU
Description
SENSOR SETUP
TYPE
ENABLE
SENSOR1 SENSOR2 SENSOR3 SENSOR4
NO
NO
NO
NO
SENSOR
Customize the initial state of the attached sensor.
ENABLE
Active/deactivate the sensor.
TYPE
Select the state of the sensor.
-
NO: Indicates that the initial state of the sensor is normal
open. Video recording initiates when there is a changes in
the sensor state
-
NC: Indicates that the initial state of the sensor is normal
close. Video recording initiates when there is a changes in
the sensor state
MOTION DETECTION SETUP
SENSTIVITY
ENABLE
CH1
CH2
CH3
CH4
5
5
5
5
MASK SETUP
MOTION DECTECION
Setup motion detection.
ENABLE
Enable/disable the channel to detect motion.
SENSITIVITY
Set the sensitivity level. The sensitivity is from HI (High), 9~ 2
and LO (Low).
MASK SETUP
Select a specific area for motion recording. The DVR system
will start recording when the selected area has been detected
motion.
