OSD MENU Description
MAIN MENU
CAMERA/RECORD
SCHEDULE
EVENT SETUP
DISPLAY
STORAGE
SYSTEM
DISPLAY
Configure the parameters of video and setting of spot monitor.
DISPLAY SETUP
COLOR ADJUSTMENT
VIDEO SHIELD
VGA - TV SELECTION
VIDEO OUT SETTING
SPOT MONITOR
EVENT TYPE
AUTO SCAN
CH1
MAIN - MAIN
QUAD
ADJUSTABLE
EVENT DURATION 010 SEC
DISPLAY SETUP
COLOR ADJUSTMENT
VIDEO SHIELD
VGA - TV SELECTION
VIDEO OUT SETTING
SPOT MONITOR
EVENT TYPE
AUTO SCAN
CH1
MAIN - MAIN
QUAD
ADJUSTABLE
EVENT DURATION 010 SEC
COLOR ADJUSTMENT
To adjust the brightness, contrast, hue, and saturation value of
channel video. To reset the setting, select RESET TO
DEFAULT VALUE.
COLOR ADJUSTMENT SETUP
CONTRAST
BRIGHTNESS
HUE
SATURATION
CH1 CH2 CH3 CH4
RESET TO DEFAULT
001 001 001 001
054 054 054 054
124 124 124 124
121 121 121 121
VIDEO OUT SETTING
To select the sharpness, color enhancement, VGA mode,
resolution of VGA and TV out setting.
VIDEO OUT SETUP
COLOR ENHANCEMENT
SHARPNESS
VGA MODE
RESOULTION
VGA TV
MODE1 -
SVGA -
00 00
00 00
SHARPNESS
Adjust the sharpness of VGA and TV video output.
COLCOR ENHANCEMENT
Adjust the color enhancement of VGA and TV video output.
VGA MODE
Select the VGA output mode.
RESOLUTION
Select the resolution of VGA video output.
