26
OSD MENU Description
MAIN MENU
CAMERA/RECORD
SCHEDULE
EVENT SETUP
DISPLAY
STORAGE
SYSTEM
RECORD SCHEDULE
By default, in 24 hours, the recording schedule is set to always
record every hour. Refer to the table below to customize the
recording condition.
Condition Description
ALWAYS Record non-stop.
SMART
Automatically switch to recorded at the maximum
frame rate setting once a motion is detected and if
there is no motion, it records at the minimum frame
rate setting.
ALARM Start recording when the sensor is activated.
CAMERA
Select a channel (1, 2, 3, or 4) or ALL for record schedule
setup.
SET TO ALL
Select a recording condition – ALAWAYS, SMART or ALARM.
Please refer to the above table for record condition description.
RECORD SCHEDULE
SUN
CAMERA
SET TO ALL
ALL
ALWAYS
MON
TUE
WED
THU
FRI
SAT
00 02 04 06 08 10 12 14 16 18 20 22 24
: ALARM RECORD
: SENSOR RECORDING
