Page 19
15
Playback Mode
Symbol
Description
Playback the recorded video
Audio is enabled
AB segment is set and playing
Recorded video is playback at backward speed(2x, 4x, 8x, 16x, 32x, or 64x)
Recorded video is playback at faster forward speed(2x, 4x, 8x, 16x, 32x, or 64x)
A
Always Recording
B
Button Recording
M
Motion Recording
Screen type
User can switch to display each channel in full screen or 4 channels in D1, D1 Enhanced, or
CIF record mode.
Full Screen Mode
QUAD Screen Mode
When you are in full screen preview, press the following buttons on the remote control and
control panel to switch to different channel, or preview all 4 channels:
1
CH1: Camera 1
3
CH2: Camera 2
7
CH3: Camera 3
9
CH4: Camera 4
5
QUAD:4-Channel
