23
OSD MENU Description
CAMERA NAME SETUP
CH3
CH2
CH1
CH4
CAMERA1
CAMERA2
CAMERA3
CAMERA4
CHANNEL NAME
Give a name for the channel 1 ~ 4. Maximum is 12 characters
and can enter A~Z, 0~9, !, “, #, $, %, &, ‘, (, ), *, +, -, /, :, ;, <.
>, ?, @, and space.
PTZ SETUP
ID
ENABLE
PROTOCOL
BAUD RATE
CH1 CH2 CH3 CH4
AUTO PAN
DWELL TIME
010S 010S 010S 010S
OFF OFF OFF OFF
9600
CANON VC - 4CR
001 002 003 004
PTZ SETUP
To enable PTZ camera control by remote control and setup
PTZ camera parameters.
ENABLE
Select the channel of PTZ camera. If the PTZ camera is
connecting on channel 1, then select the camera 1 for PTZ
video to be display on channel 1.
ID
Assign an ID to PTZ camera. The ID range is from 001 to 255
but is limiting by protocol of PTZ camera. Please refer to your
PTZ camera user’s manual for more detail of PTZ ID
assignment.
i We suggest assigning PTZ camera ID star from 5 to
avoid conflict with ID of camera channels.
PROTOCOL
Select the protocol of PTZ camera. The protocol will be different
that depends on the brand of PTZ camera. The DVR system
currently supports 3 protocols ─ PELCO-D, PELCO-P, and
CANON VC-C4R. Please refer to your PTZ camera user
manual to make sure which protocol is using for.
BAUD RATE
To setup the baud rate of PTZ camera. For more detail, please
refer to your PTZ camera’s user manual.
AUTO PAN
Select the preset number to assign an auto move direction for
the PTZ camera. For example: 1-4 means the PTZ camera will
auto move from preset position 1, 2, 3 to 4.
DWELL TIME
Set a time that how long the PTZ camera stays in that position
before it moves to the next one.
