HVLS-1000 Series Fluid Section Manual
Rev. 05/2012 Page | 34
PROBLEM CAUSE SOLUTION
Narrow Fan
Wide Fan Material too cold, nozzle too large
or air pressure low. Heat Material, use smaller
nozzle, or as a last resort
increase pump pressure.
Resin filter clogged. Disassemble and clean the resin
filter.
Air pressure too high. Lower pressure then increase
pressure to the desired fan.
Nozzle too small or too wide. Change nozzle.
Round fan Orifice in nozzle worn, clogged,
or damaged. Push fine wire through orifice
from back side. Use fingernail to
clean material form “V” shaped
notch in front. Soak hardened
material in solvent. If notch is
rough or worn, replace nozzle.
Air-assist pressure too high. Decrease air-assist pressure.
Excessive Misting
Heavy pulsation Air pressure too high. Reduce air pressure to gel coat
pump.
Resin accumulator plugged.
Danger: To prevent injury,
always relieve fluid pressure
before attempting to remove
components. Disassemble accumulator and
clean.
Pump jumps on upstroke
Piston ball worn or not seating
properly. Replace piston ball and piston
cups. Be sure to lubricate ball
and cups thoroughly with Red
Grease.
Pump dives on down stroke Foot valve, spring retainer, or foot
valve ball damaged or dirty. Clean or replace foot valve,
spring retainer and foot valve
ball. Be sure to lubricate ball
thoroughly with Red Grease.
Pick-up wand assembly not tight. Tighten or seal joints of pick-up
wand.
Air in material. Agitate material to remove air.
Low output on upstroke Piston cups, piston ball, or pump
cylinder worn. Inspect the piston cups, piston
ball, and pump cylinder. Clean
and replace any damaged
components.
