HVLS-1000 Series Fluid Section Manual
Rev. 05/2012 Page | 19
7. Hose connections.
a. Connect the black resin hose from the gun to the outlet fitting on the resin filter.
b. Connect the catalyst hose from the catalyst pump to the inlet of the catalyst manifold.
c. Connect the catalyst hose from the gun to the outlet of the catalyst manifold assembly.
d. Attach the red air hose from the gun to the fitting on the regulator labeled gun.
e. Attach the yellow poly flush hose from the gun to the outlet fitting of the solvent tank.
f. Attach the small red air supply hose from the flush regulator to the input fitting on the
solvent tank.
g. Attach the large red air hose from the pump regulator to the power cylinder of the resin
pump.
Note: Check all hose fittings and fluid connections to make sure they are tight.
h. Attach the ground wire from the gun to the electrical grounding lug on the pump
mounting bracket.
Note: Check electrical ground to ensure it is installed from the pump mounting bracket to
an earth ground.
i. Remove the catalyst poly tubes from the component box.
j. Cut the ½ inch diameter poly line, with the clamps, to 26 inches long. Clamp one end to
the outlet of the catalyst jug and the other end to the inlet of the catalyst pump. Make
sure clamps are airtight.
k. Connect the ¼-inch poly line to the relief valve on the catalyst manifold assembly and
insert the other end into the hole in the top of the catalyst jug.
l. Connect the ¼-inch poly line to the catalyst recirculation valve on the catalyst manifold, and insert
the other end into the hole in the top of the catalyst jug.
9.
Check all components for damage.
