IT400 Remote Totalizer & Rate Indicator Page: 25 DOC#: MN-IT400-R2d.doc
Appendix 1: Menu Quick Reference
1.
Reset Totalizer
Done
2.
Enable Temperature
Compensation
Reference Temperature*
{60.0}
Coefficient of Thermal
Expansion* {0.0001015}
3.
Enable Linearizer
Edit Linearizer Table
Table Points*
4.
K Factor (if Linearizer is
disabled)* {60.0}
5.
Totalizer Units
0) Gallons
1) Liters
2) Pounds*
3) Cubic Feet
4) Cubic Meters
5) Barrels
6) Kilograms*
7) Custom*
6.
Totalizer Decimal Place
0) 0.01
1) 0.1
2) none
3) x10
4) x100
7.
Ratemeter Units
0) Gallons
1) Liters
2) Pounds*
3) Cubic Feet
4) Cubic Meters
5) Barrels
6) Kilograms*
7) Custom*
8.
Ratemeter Decimal Place
0) 0.001
1) 0.01
2) 0.1
3) none
4) x10
5) x100
6) Auto-range
9.
Ratemeter Time-base
0) Seconds
1) Minutes
2) Hours
3) Days
4) Custom*
10.
Enable 4-20mA Output
4-20mA Output Low* {0.0}
4-20mA Output High *
{99999.0}
11.
Enable Pulse Output
Pulse Width
0) Frequency
1) 1 ms
2) 2 ms
3) 5 ms
4) 10 ms
5) 50 ms
6) 100ms
7) Custom*
Pulse Output Divider
0) 1
1) 2
2) 5
3) 10
4) 50
5) 100
6) 1000
7) Custom*
12.
Backlight Timer
0) Disabled
1) 2s
2) 5s
3) 10s
4) 30s
5) 1m
6) 3m
7) 5m
8) Always On
9) Custom*
13.
Power Mode Selection
0) Mode 1 refresh 16/s
1) Mode 2 refresh 8/s
2) Mode 3 refresh 4/s
3) Mode 4 refresh 1/s
4) Mode 5 refresh 2s
14.
Alarm Bits
Low Battery
Temperature Under
Temperature Over
Rate Under
Rate Over
No Totalize During Alarm
15.
Service Hours
Service Hours Set Point
Service Hours Set Point
Edit/Reset* {1000}
16.
Datalogger
17.
Real-Time Clock
18.
Warnings
Flow Rate
Low* {0.0}
High* {9999999.2}
Temperature
Low* {-350.0}
High* {200.0}
Temperature Sample Delay
0) 1s
1) 2s
2) 5s
3) 10s
4) 30s
5) 1m
6) 3m
7) 5m
8) 10m
9) Custom*
19.
Unit Test
Raw Frequency
RTD ohms
DC Input / Battery Voltage
(DC in if > 2.7Vdc)
LCD Test
4-20mA Output Test %
0) 0
1) 25
2) 50
3) 75
4) 100%
Software Version
20.
Enable Menu Lockout
Menu Lockout Code*
{1000}
* User Editable value
Default values in bold. Your default values may be different depending on the configuration requested at order time.
