Laurel Electronics LAUREATE SERIES DPM User Manual
Page 13
-11-
TRUE RMS SIGNAL CONDITIONER
VALUE SELECT KEY
MENU KEY
DIGIT SELECT KEY
TEMPERATURE SIGNAL CONDITIONER
InPut
Input signal type
J°F J°C K°F K°C t°F
t°C E°F E°C S°F S°C
r°F r°C
n°F n°C
Types
J, K, T, E, N, S, R in °C or °F
4d °F 4d °C
DIN 4-wire
4A °F 4A °C
ANSI 4-wire
3d °F 3d °C
DIN 3-wire
3A °F 3A °C
ANSI 3-wire
2d °F 2d °C
DIN 2-wire
2A °F 2A °C
ANSI 2-wire
Short
Compensation for
2-wire lead resistance
0.2U 2.0U 20.0U
200.0U 660.0U
0.2, 2, 20, 200, 660 V FS
2.0a 20.0a 200.0a 5.0A
2 , 20, 200 mA, 5 A FS
0.2U 2.0U 20.0U
0.2, 2, 20 V FS
0.2U 2.0U 20.0U
200.0U 660.0U
0.2, 2, 20, 200, 660 V FS
2.0a 20.0a 200.0a 5.0A
2 , 20, 200 mA, 5 A FS
DC SIGNAL CONDITIONER
tC
Thermocouple
Note: Display = K
rtd
Pt 100 Ohm RTD
dC U
DC Volts
dC A
DC Amperes
rAtio
Strain Gauge
AC U
AC Volts
AC A
AC Amperes
