PIO-48.PC104 User Manual
Physical Installation
Extreme care should be taken when installing the PIO-48.PC104 to avoid causing
damage to the connectors. After the adapter is installed, connect your I/O cables to
P2 and P5. Please note these headers are keyed so that pin 1 of the cable matches pin
1 of the connector. Refer to Card Setup for information on setting the address and
jumper options before inserting the PIO-48.PC104 onto the stack.
Do not install the Adapter in the machine until the software has been fully
installed.
1. Turn off power. Disconnect the power cord.
2. Gently insert the PIO-48.PC104 connector noting proper key orientation of
the expansion connector on a PC/104 compatible card. The PIO-48.PC104
adapter is keyed per the current PC/104 Specification. This will aid in
preventing the adapter from being inserted incorrectly.
3. Mounting hardware (nylon stand-offs and screws) is provided to ensure a
good mechanical connection. Retain any mounting hardware not used to
allow for future expansion.
4. The cables provided are keyed and can be installed before or after the adapter
is inserted in the stack.
5. Connect the power cord and power up the machine.
The PIO-48.PC104 is now ready for use.
3
rd
Party Software Support
Third party software support for many HMI/MMI and other process control software
is included on the product installation CD. For the most up to date information on
third party software support, please visit:
