Impulse PIO-48.PC104 (3701) User Manual
Page 7
© Sealevel Systems, Inc.
- 5 -
PIO-48.PC104 User Manual
IRQ Selection
The PIO-48.PC104 has an interrupt selection jumper, which should be set prior to
use, if an interrupt is required by your application software. Consult the user manual
for the application software being used to determine the proper setting.
IR
Q
3
IR
Q
4
IR
Q
7
IR
Q
5
IR
Q
9
IR
Q
1
0
IR
Q
1
1
IR
Q
1
2
IR
Q
1
5
Note: The supplied driver for Windows and does not require, nor does it support
interrupts. It is recommended that this jumper be removed to prevent any resource
conflicts.
