Overview of the Smart DC Controller
4-8 SlideSmart Installation and Reference Manual Revision B
Figure 4-4. Standard 11-Pin Box Type Vehicle Detector
V EHICLE D ETECTOR C ONFIGURATION AND Q UICK C LOSE M ODE
S
ELECTION
24VAC or 24VDC
Connect detector to match
its voltage rating
The center loop serves no
gate function but the detector
can be used as an arming loop
when used in conjunction
with User
Relay 22.
