SlideSmart Components

Intro-1

SlideSmart Installation and Reference Manual

Revision B

S

LIDE

S

MART

C

OMPONENTS

Cover

Motor

Gearbox

Sprocket

Idler, 2x

Control Box

Board, Smart
DC Controller

Buzzer

Switch, Reset
Emergency
Stop button

Battery kit, 8Ah

Cover, Latch

DC Switch,
On/Off

AC Switch,
On/Off

Circuit
Breaker

115VAC
Service
Outlet

Board, Power supply

Pulley, Gearbox
Belt Drive, 2ft/s

Protection plate &
Cover

Transformer

Pulley, Motor

Serial # location

Pulley, Gearbox
Belt drive, 1ft/s

Brush kit

WARNING Label

Target sensor (2x)

Base plate

Note:
