Aligning the chain, Top view, Side view – Controlled Products Systems Group SLIDESMART DCS 10F User Manual
Page 31
Gate Bracket and Chain Installation
Revision B
Installation
1-9
Aligning the Chain
Figure 1-12.
Sprocket
Idler wheel
Target sensor
(RH gate)
Target
sensor
(LH gate)
Figure 1-13.
Too close to gate
CORRECT INSTALLATION
INCORRECT INSTALLATION
INCORRECT
INCORRECT
CORRECT
TOP VIEW
Chain to gate
Ideal distance = 3¾"
(9.5cm)
SIDE VIEW
Keep chain horizontal to the ground.
