Gate Bracket and Chain Installation
1-14
SlideSmart Installation and Reference Manual
Revision B
F
RONT
I
NSTALLATION
Figure 1-19.
CAUTION
Roller chain sprocket
Idler wheel
Target
(LH gate)
sensor
Position of the target
magnet when the gate is
fully closed.
Second target
sensor is not used
Trailing edge of gate
(Gate shown in full
CLOSE position)
