Concrete Pad Mount
Revision B Installation 1-7
C
ONCRETE
P
AD
M
OUNT
Figure 1-9.
Chain
#40 Roller
slotted holes (4x) for
concrete anchors:
½ - 13 x 3½"
Concrete
pad
Gate
Chain to Gate
Ideal distance =
Minimum distance = 2½" (5cm) 3¾" (9.5cm)
Chain resides
inside gate
support posts
Gate support
posts
Gate support
posts
Left hand gate
SlideSmart
parallel with the
gate.
Mark the center of
Figure 1-10.
½ - 13 x 3½"
anchors (4x)
concrete Concrete
pad
Grade
level
Concrete
base
Tip: To keep pinpoint accuracy while drilling
the mounting holes in the concrete, use a
3/16-inch bit to pilot the holes and then move
to a ½-inch drill bit.
