Vehicle detector installation options – Controlled Products Systems Group SLIDESMART DCS 10F User Manual
Page 86
Overview of the Smart DC Controller
4-4
SlideSmart Installation and Reference Manual
Revision B
Vehicle Detector Installation Options
NOTE
Figure 4-3. HY-5A Vehicle Detector Module
Rear V iew
Front View
Loop wire
connections
Sensitivity dial
adjustment
Status LED
Standoff Supports
(Inset into the
holes in the
Control Box.)
