Installing the extended battery backup kit, Danger – Controlled Products Systems Group SLIDESMART DCS 10F User Manual
Page 50
Important Considerations for DC-powered Operators
2-12
SlideSmart Installation and Reference Manual
Revision B
Installing the Extended Battery Backup Kit
Figure 2-8.
DANGER
!
50Ah batteries
Accessory tray
Post-mounted
operator with
base extension
Posts not included
in kit
Figure 2-9.
8Ah battery
Control box
Wire ties
8Ah battery
Screws
(4x)
Access window
