www.ramsetinc.com

6

RAMSET

Figure 4

Figure 5

Figure 6

REAR INSTALLATION GATE SHOWN

Fully Open

No tail on gate required

CENTER INSTALLATION

GATE SHOWN

Fully Open

No tail on gate required

FRONT INSTALLATION

GATE SHOWN

Closed

Tail on gate required

Note:

This type of
installation
does not apply
for model
RAM 100

Note:

This type of
installation
does not apply
for model
RAM 100

Top View

Top View

Front View

Front View

Hidden Wall

Wall

TAIL

TYPES OF INSTALLATIONS:

Inside

Property

Outside

Property

Inside

Property

Inside

Property

Outside

Property

Outside

Property

WARNING:

USE ONLY CHAIN

GUARDED PULLEYS

WARNING:

USE ONLY CHAIN

GUARDED PULLEYS
