Controlled Products Systems Group LA400-S User Manual

Page 2

OPERATOR SPECIFICATIONS

Tools Needed for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Carton Inventory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Additional Items Needed for Installation . . . . . . . . . . . . . . . . . . .3

Operator Dimensions and Specifications . . . . . . . . . . . . . . . . . . .3

UL325 Classifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

OPERATOR WARNINGS

Safety Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Suggested Entrapment Protection Device Locations . . . . . . . . . .6

Warnings and Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Warning Sign Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

INSTALLATION

Gate Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Pull-to-Open Bracket Mounting Instructions . . . . . . . . . . . . . . . .9

Push-to-Open Bracket Mounting Instructions
(for use with Accessory Kit 50-19503) . . . . . . . . . . . . . . . . .10-11

Control Box Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Control Box Mounting with U-Bolts . . . . . . . . . . . . . . . . . . . . . .12

WIRING

Connect Arm to Control Box . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Earth Ground Rod Installation . . . . . . . . . . . . . . . . . . . . . . . . . .13

Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

BASIC CONTROL BOARD SETUP

Set Dip Switch for Gate Type . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Programming Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Wire Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Optional Control Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-20

Force and Timer to Close . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Program Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

DIP Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

OPERATION AND MAINTENANCE

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Manual Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

ACCESSORIES

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

WIRING DIAGRAM

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

TROUBLESHOOTING

. . . . . . . . . . . . . . . . . . . . . . . . . . .27-28

REPAIR PARTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29-30

WARRANTY POLICY AND SERVICE

. . . . . . . . . . . . . . . .32

When you see these Safety Symbols and Signal Words on the
following pages, they will alert you to the possibility of serious
injury or death if you do not comply with the warnings that
accompany them. The hazard may come from something
mechanical or from electric shock. Read the warnings carefully.

When you see this Signal Word on the following pages, it will
alert you to the possibility of damage to your gate and/or the gate
operator if you do not comply with the cautionary statements that
accompany it. Read them carefully.

Mechanical

Electrical

T A B L E O F C O N T E N T S

WARNING

CAUTION

WARNING

CAUTION

WARNING

IMPORTANT NOTE

• BEFORE attempting to install, operate or maintain the operator,

you must read and fully understand this manual and follow all
safety instructions.

• DO NOT attempt repair or service of your commercial door and

gate operator unless you are an Authorized Service Technician.

WARNING

CAUTION

WARNING

TOOLS NEEDED FOR INSTALLATION

During assembly, installation and adjustment of the operator the
tools listed below will be needed.

• Wrench or Socket Set

• Phillips Head Screwdriver

• C Clamps

• Level

• Small Screwdriver

• T25 Torx Head Screwdriver
