40
REPAIR PARTS
NOT SHOWN
K94-36250
Battery Harness (for 7AH batteries)
K94-36531
Wiring Harness with ID Resistor
30 Amp Fuses
1941240D
#41 Chain (10 feet)
1950307
#41 Master Link
77-50382
Hardware: Chain Eye-bolts with Nuts, Chain
Bracket (2), Crank Handle
Q003
Chain
Bolt
Q004
Chain
Bracket
K80-36544
Vent
Plug
K74-30762
Two 7AH batteries
K94-36596
Battery Harness (for 33AH batteries)
K75-34986-2
7AH Heater/Battery Bracket
ITEM PART
NUMBER
DESCRIPTION
1 K73-34718-2
Chassis
2
K77-36480
Operator Cover with labels, keys, and lock
assembly
3
K76-34697
APS Encoder, 24V
4
K16-GT2-7
Timing Belt, 3M
5
K17-36530
Gear Reducer Pulley and Motor Pulley
6 K15-41B17LKGH Output
Sprocket
7 K32-34669-1
Gear
Reducer
8 K204C0211
Toroid
Transformer
9
K1A6408
APE Assembly with plastic tray, RPM board
with mounting hardware
10 K52C0481
Bridge
Rectifier
11
K1D6597-1CC
Main Board with heat sink
12 K1D6686CC
Expansion
Board
13
K76-34728
EMI Board with 120V receptacles and AC
power switch
14 K77-36541
Antenna
15 K76-36398
Motor,
1/2
HP,
24
Vdc
16 K77-36542
Electrical
Box
with
junction
box
17 K180A0357
Reset
Switch
18 K94-35152
Alarm
with
harness
19 K75-36260
Lock
and
Keys
20 Q118
Keys
21 K13-34729
Dust
Guard
22
Q013
Idler Pulley with hardware
23 29-NP712
Battery,
7AH,
12
Vdc
INDIVIDUAL PARTS
