17
DUAL GATES ONLY
DUAL GATES ONLY
WIRING
Outside
Pr
oper
ty
Inside Pr
oper
ty
!
!
COMM LINK
B
A
OM
N.C.
COMM LINK
B
A
OM
N.C.
2
1
3
4
Comm Link Data A
Comm Link Data B
Comm Link Data A
Comm Link Data B
Before digging, contact local underground utility locating companies. Use PVC conduit to prevent damage to cables.
1
Trench across driveway to bury the extension cable.
2
Connect the wires from the extension cable to the Comm Link terminals
on the primary gate operator control board.
3
Route the extension cable to the secondary gate operator's control
board.
4
Connect the wires from the extension cable to the Comm Link terminals
on the secondary control board (Comm Link A to Comm Link A and
Comm Link B to Comm Link B).
There are two options for dual gate communication: wired or wireless. Follow the directions according to your application. Do not use
wired and wireless communication simultaneously. Wired dual gate applications will have a longer battery standby time than wireless applications.
WIRED DUAL GATES
DUAL GATE WIRE TYPE (STRANDED COPPER WIRE)
22AWG up to 200 feet (61 m) 18AWG - 200-1000 feet
(61-305 m)
Wire must be rated at 30 Volt minimum
