Controlled Products Systems Group AOMSW350DC - Manual (Page 7)

24”
30”
25 ”
9” 15”
1
1
/
2
/
2
1 /
2
24”
4”
”
”
21
14
1
4
17 / ”
Operator plastic
cover
Operator frame
1 /
2
1 /
2
Four red head
Bolts ” ” X 3
Area for Conduit(s)
Operator concrete pad
When possible
install 4” above
ground
Footing for
gate operator
Low voltage single
conduit for Master/Slave
High voltage
conduit
CONCRETE PAD FOR SW-350DC
6
