This is a normal loop layout. Remember when connecting to an All-O-
Matic circuit board you use the

your

safety loop detector and

from the exit loop.

You must twist your wires from your exit point of the saw cut all the way
to the circuit board, no exceptions.

normally closed contacts

normally open contacts

from

SWINGER LOOP LAYOUT

Outside Safety loop

Inside Safety loop

Center Phantom loop

5 FT

5 FT

5 FT

5 FT

5 FT

5 FT

Gate in open
position

Gate in open
position

Exit loop

1/4 IN

1/4 IN

1 1/2 IN

TWISTED 6

TURNS

PER FOOT

WIRED IN SERIES

WHEN USED
