Beam

MULTIPLE SAFETY DEVICES

CONNECTIONS

Multiple

devices installed together must be connected

.

.

efore installing the accessory devices, remove the wire

jumper from the

position

in series

SAFETY

SAFETY

SAFETY

Locate the white loop rack safety wire and connect with common wire of
second device. Dry contact (N.C.) from second device goes to

on

the circuit board B

on the control board.

From Second Accessory To Board pin

Relay N.C.

To SAFETY

From Loop rack to Second Accessory

White safety wire

To Relay COM

This diagram is for the relay wires of the safety devices, two wires to the board connections (one from
each device) and two wires to the orange wire nut.

Wire nut

Safety wire connections

Remove

jumper

from

when

a safety device is

installed.

wire

SAFETY

Relay (COM)

Relay
(N.C.)

AB

C8RB
