COnCReTe paD COnSTRuCTIOn anD layOuT
The gate must roll freely with no binding of the wheel, guides, and/or gate hardware before any operator is
connected to the gate.
DR3020/DR3020HX
20” - Mounting Holes
10”
4”
4”
2
1 /
2
”
1
1 /
2
”
1˝
26” Pad Size Minimum
18”
Electrical Stub Up Area
Chain
Gate
Wall
22” - Cover Size
12
1
/ 2
”
10
1
/ 2
”
Figure 3 (Top View)
13”
Operator
DR 3020 / DR 3020HX
Figure 4 (Front Mount)
