Page 23
22
PROSTAR ELECTRIC HOIST
PARTS LIST
Key
Number
Part Name
No.
Req’d
Part
Number
620-168 Dead End Plate Screw, (Double chained)
2
73715
620-169
Capacity Warning Label
250 lbs.(113Kg)
300 lbs.(136Kg)
500 lbs.(226Kg)
550 lbs.(250Kg)
600 lbs.(272Kg)
1,000 lbs. (453Kg)
1,100 lbs.
1
1
1
1
1
1
1
20762
20737
20763
20509
20738
20884
20514
620-170 I.D. Label
1
Contact
Factory
620-171 Warning Label
2
24842
620-172 Prostar Label
1
20764
620-173 Wire Nut (not shown, specify No. Req’d)
-
920756
620-174 Gasket
1
20755
620-176
Control Cord Assembly
(includes cord, strain relief and warning tag)
For Black Control Station and
10 ft. lift
15 ft. lift
20 ft. lift
For other lifts, contact factory
1
1
1
-
20675
20676
20677
-
650-177 Frame Spacer
1
20333B
620-178
Contactor (includes power jumpers)
115 VAC Coils
48 VAC Coils
1
1
20814
20787
Key
Number
Part Name
No.
Req’d
Part
Number
620-179 Components Board - Outboard
1
20777
620-180 Components Board - Inboard
1
20778
620-181
Transformer
48 Volt Secondary (220/380 primary)
48 Volt Secondary (change to 460/60 Hz or
380/50Hz primary)
115 Volt Secondary (230/460 primary)
115 Volt Secondary (575 primary)
48 Volt Secondary (575 primary)
1
1
1
1
1
20851
20834
20831
20876
20866
620-182
Diode Assembly
1
20789
Diode/TVS Assembly
1
20383
620-183 Control Cord Plug
1
20780
620-184 Power Cord Plug
1
20781
620-185 Contactor Jumper (Specify No. Req’d)
-
20332
620-187
Voltage Suppressor
230-3-50/60, 380-3-50 and 460-3-60 Hoists
575-3-60 Hoists
1
1
20861
20869
620-188 Ground Jumper
1
20641
620-189 Chain Guide Screw
1
987859
620-190 Chain Guide Spacer
1
20812
620-191 Warning Label
1
20765
620-192 Chain Guide Stripper
1
20622
620-193 Brake Spacer
1
20723
620-196
Hook Block Screw Lockwasher (Double Chained)
2
940802
Hook Block Screw Lockwasher (Single Chained)
2
983544
620-197 Warning Label
1
24884
620-198 Hook Block Screw Nut (Single Chained)
2
82638
Part Number for Packaged Lubricants
Used in the Prostar Hoist
(Refer to Page 8 for Lubrication Instructions)
Part Numbers and
Lubricant
Type
Packaged Quantity
Usage
Lubricant
of Lubricants
Grease
28605 for 1/2 lb. Can
Hoist Gears
Century
28616 for 1 lb. Can
Lubricants HB-11, #3
28617 for 4 lb. Can
Spline on end
Oil-Graphite Mixture
First Pinion
Hercules Packing Co.
40628 for 1 Pint Can
and Shaft
Moly-Duolube 67
Oil
Load Chain
Fiske Bros.
28608 for 1 Pint Can
Lubriplate® Bar and
28619 for 1 Gal. Can
Chain Oil #10R
Grease
28606 for 1/2 lb. Can
Lower Hook Knob
Dow Corning
28618 for 1 lb. Can
Molykote BR-2-S
When ordering lubricants, specify the type of lubricant, part number and packaged quantity required.
Touch-up Paints for Prostar Hoist:
Order *(1) case (12-12 oz. Aerosol Cans) of Black Touch-up paint Part Number 84189.
*Touch-up paints are only available in case quantities.
NOTE: When painting hoists, also order warning labels, etc. that may be coated during painting.
