PROSTAR ELECTRIC HOIST
PARTS LIST
KEY
NUMBER
PART NAME
NO.
REQ’D
PART
NUMBER
620-100
Stator
115-1-50/60 Hoists
220-1-50 Hoists
220-3-50/60 Hoists
380-3-50, 415-3-50 and 460-3-60 Hoists
575-3-60 Hoists
1
1
1
1
1
20707
20328
20329
20330
20344
620-101 Rotor Assembly (Includes 620-102 and 620-103) 1 20651
620-102 Rotor Bearing, Outboard 1 88487
620-103 Rotor Bearing, Inboard 1 88486
620-104 Rotor Thrust Washer 1 20727
620-105 Motor End Cover 1 20321
620-106 Capacitor
115-1-50/60 Hoists
220-1-50 Hoist
1
1
20708
20785
620-107 Main Frame (Includes 620-108 and 620-109) 1 20353
620-108 Liftwheel Seal 1 20705
620-109 Protector Bearing, Main Frame Side 1 88636
620-110 Cut-Out Device
115-1-50/60 Hoists 1 20709
620-111
Protector Assembly
6 fpm (1.8mpm), 1,000 lbs. (453Kg)
8 fpm (2.4mpm), 500(226Km) & 600 lbs.(272Km)
8 fpm (2.4mpm), 1000 lbs. (453Kg)
12 fpm (3.7mpm), 500 lbs.(226Kg)
12 fpm(3.7mpm), 600 lbs.(272Kg)
12 fpm(3.7mpm), 1000 lbs.(453Kg)
13.4 fpm(4.0mpm), 550 lbs.(250Kg)
16 fpm(4.9mpm), 250(113Kg) & 300 lbs.(136Kg)
16 fpm(4.9mpm), 500 lbs.(226Kg)
20 fpm(6.1mpm), 500 lbs(226Kg)
20 fpm(6.1mpm), 600 lbs.(272Kg)
24 fpm(7.3mpm), 250(113Kg) & 300 lbs.(136Kg)
24 fpm(7.3mpm), 500 lbs.(226Kg)
40 fpm(12.2mpm), 250 lbs.(113Kg)
40 fpm(12.2mpm), 300 lbs.(136Kg)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
20665
20645
20660
20665
20638
20662
20660
20645
20660
20648
20661
20638
20662
20648
20661
620-112 Protector Thrust Washer 2 88640
620-113 Gear Housing (Includes 620-114 and 620-115) 1 20351
620-114 Protector Bearing - Gear Housing Side 1 88636
620-115 First Pinion Bearing 1 88635
620-116 Brake Base Plate 1 20724
620-117 Brake Disc 1 20698
620-118 Brake Armature 1 20420
620-122
Brake Field (Includes Brake Coil)
115-1-50/60 Hoists
220-1-50, 220-3-50/60, 380-3-50, 415-3-50
and 460-3-60 Hoists
575-3-60 Hoists
1
1
1
20659
20658
20629
620-123 Brake Spring 1 20887
620-124 Brake Screw 4 920740
620-125 Pin Retainer Plate 1 20700
620-126 Pin Retainer Plate Screw 2 20743
620-127
Liftwheel and Gear Assembly
6 fpm(1.8mpm), 1,000 lbs. (453Kg)
8 fpm (2.4mpm), 500(226Km) & 600 lbs.(272Km)
12 fpm (3.7mpm), 500 lbs.(226Kg)
12 fpm(3.7mpm), 600(272Kg) & 1000lbs.(453Kg)
13.4 fpm(4.0mpm), 550 lbs.(250Kg)
16 fpm(4.9mpm), 250(113Kg), 300 lbs.(136Kg)
& 500 lbs.(226Kg)
20 fpm, 500 & 600(272Kg) lbs.
24 fpm, 250, 300 & 500 lbs.
40 fpm, 250 & 300 lbs.
1
1
1
1
1
1
1
1
1
20666
20664
20666
20647
20664
20664
20657
20647
20657
KEY
NUMBER
PART NAME
NO.
REQ’D
PART
NUMBER
620-128 Liftwheel Bearing 2 88637
620-129 Liftwheel Thrust Washer 2 88638
620-130 Liftwheel Shaft Seal 1 20704
620-131
First Pinion and Shaft
10 Tooth
12 Tooth
1
1
Contact
Factory
620-132 Brake End Cover 1 20345
620-133
Brake End Cover Screw
Hoists without contactor
Hoists with contactor
3
3
920715
20808
620-134 Gear Housing Screw 4 920718
620-136 Frame Pin 4 920720
620-137 Hook (Includes 620-138) 1 20650B
620-138 Hook Latch Kit 1 595522
620-139 Hook Retainer Kit 1 20712K
620-142 Chain Guide/Stripper Pin 4 20729
620-144 Load Chain (Specify Lift or Length Required) - 85988
620-145 Loose End Ring 1 20744
620-146 Chain Stop-Sure Stop Kit 1 20428K
620-148 Liftwheel Shaft 1 20313
620-149 First Pinion Thrust Washer 2 88639
620-150 Power Cord Grommet 1 20779
620-151
Power Cord
115-1-50/60 Hoists with contactor
220-1-50 Hoists
220-3-50/60, 380-3-50, 415-3-50,
460-3-60 and 575-3-60 Hoists
1
1
20516
20501
620-152 Power Cord Ground Screw 1 982877
620-153
Control Station and Cord Assembly
(Includes control station, cord, warning tag
and upper grommet)
Black Control Station for:
10 ft. lift
15 ft. lift
20 ft lift
For other lifts contact CM
1
1
1
20642
20643
20644
-
620-154 Motor Cover Screw 1 920719
620-155 Caution Label 1 20758
620-156 Hook Block (Single Chained)
Hook Block (Double Chained)
2
2
20995
20739
620-157 Hook Block Screw (Single Chained)
Hook Block Screw (Double Chained)
2
2
82554--
920724
620-159 Hook (Includes 620-138)
Latchlok Hook
1
1
23030
40618
620-160 Dead End Plate, (Double chained) 1 20714
620-161 Dead End Pin, (Double chained) 1 920720
620-162 Sheave Wheel w/620-164, (Double chained) 1 20652
620-163 Sheave Wheel Shaft, (Double chained) 1 20318
620-164 Sheave Wheel Bearing, (Double chained) 1 88641
620-165 Sheave Wheel Thrust Washer, (Double chained) 2 88639
620-166 Jumper (#2) 1 20610
620-167 Jumper (Cap) 1 20609
620-168 Dead End Plate Screw, (Double chained) 2 73715
