ASSEMBLY INSTRUCTIONS

Suggested Tools:
Wrench and/or Ratchet Set
1.5mm Allen Wrench
Pliers
Protective Eyewear

Approximate assembly time is 20-45 minutes

CHAPIN INTERNATIONAL, INC. P.O. BOX 549 700 ELLICOTT ST. BATAVIA, NY 14021-0549 www.chapinmfg.com 800-950-4458

Full scale nuts and bolts

NOTE: Depending on model, this package may contain
additional hardware not needed for assembly.

M5 Nylon Locknut (1)

M6 Nylon Locknut (7)

M6 x 55mm Hex Bolt (6)

M6 x 45mm Hex Bolt (1)

M5 x 35mm Hex Bolt (1)

Spacer (4)

Flat Washer (1)

R- Pin (1)

Cotter Pin (1)

#8-18 x 1/2

Thread-Forming

Phillips Screw (1)

P-Clamp (1)

End Cap (2)

Cable Tie (2)

Hand Grip (2)

Bushing (2)
