24
2. Installation
2.1 Hard disk and DVD-RW Installation
2.1.1 SATA Port
 When installing HDDs, make sure to connect from SATA 1 Port.

S and E (4CH) Type
- Main board of this DVR has one SATA port: it is indicated as SATA 1.
 A Type
- Main board of this DVR has two SATA port: it is indicated as SATA 1 and 2.
 B and E (8, 16CH) Type
- Main board of this DVR has three SATA port: it is indicated as SATA 1, 2 and 3.
- Please mount DVD-RW at the SATA 3 port.
 C, D, F, G, H, I and J Type
- Main board of this DVR has five SATA ports: they are indicated as SATA 1, 2, 3, 4 and SATA 5.
- Please mount DVD-RW at the SATA 5 port.
 Up to five SATA devices (HDD and DVD-RW) are able to be connected to the SATA ports in serial; however the devices must
be connected onto correct SATA port.
 Refer to the table below to mount HDDs and DVD-RW.
S and E (4CH) Type
4 / 8 CH DVR
Storage
SATA 1 Port
HDD
1 HDD
A Type
4 / 8 / 16 CH DVR
Storage SATA 1, 2 Port
HDD 1 2
1 HDD ---
2 HDD HDD
B and E (8, 16CH) Type
4 / 8 / 16 CH DVR
Storage SATA 1, 2, 3 Port
HDD DVD-RW 1 2 3
1 1 HDD --- DVD-RW
2 1 HDD HDD DVD-RW
2 0 HDD HDD ---
C, D, F, G, H, I and J (8, 16CH) Type
4 / 8 / 16 CH DVR
Storage SATA 1, 2, 3, 4, 5 Port
HDD DVD-RW 1 2 3 4 5
1 1 HDD --- --- --- DVD-RW
2 1 HDD HDD --- --- DVD-RW
3 1 HDD HDD HDD --- DVD-RW
4 1 HDD HDD HDD HDD DVD-RW
4 0 HDD HDD HDD HDD ---
