162
11.4 Setup
11.4.1 DVR Control Mode
 Press + in DVR Mode to enter Main Setup and enter password. (Default password is 0000)
Keyboard Detail Option
VER Firmware version -
DATE Date setting YY/MM/DD
TITLE SET Camera title -
CONTROL ID ID No. Change -
DVR SPD Set Baud rate 2.4Kbps~57.6Kbps
COMM Communication setting RS422 / RS485
BACKLIGHT Backlight setting for LCD OFF / ON / AUTO
SLEEP Sleep mode setting OFF / 1Min / 5Min / 10Min / 30Min / 1 Hr
BUZZER Buzzer setting OFF / ON
TERMINATE Termination OFF / ON
JOYSTICK SPD Joystick speed 50MS~300MS
PASSWORD Change password Default password: 0000
FACTORY SET Factory reset -
SAVE/EXIT Save and Exit NO / YES
11.4.2 Speed Dome Setup
 Press + in SPD Mode to enter Speed Dome Setup and enter password. (Default password is 0000)
Keyboard Detail Option
ADDRESS Camera ID number 1~255
MODEL Select Camera -
PROTOCOL Set Protocol PEL-D / PEL-P / W-DRX / SAM-E / LGP /
SAM-T / PANAS / VICON / AD / HWELL
BAUDRATE Set Baud rate 2.4Kbps~57.6Kbps
PARITY Set Parity NONE / EVEN / ODD
PROP Set Camera speed
Slow PTZ => PROP: ON
Speed PTZ => PROP: OFF
11.4.3 Joystick Calibration
 Press + to enter Joystick Calibration and enter password. (Default password is 0000)
Keyboard Detail Option
PTZ OFFSET Rest position value setting -
PAN LEFT Left Pan value setting -
PAN RIGHT Right Pan value setting -
TILT UP Tilt Up value setting -
TILT DOWN Tilt Down value setting -
ZOOM WIDE Zoom Wide value setting -
ZOOM TELE Zoom Tele value setting -
