Kolpin FRB-48_60 – Rear Blade User Manual
Page 2
Assemb ly Instruct io ns:
1. Secure #2 (Cutting Edge) to #1 (Blade Assembly) with 5/6” Carriage Bolts, Washers
and Nylock Nuts.
2. Secure #4 (Swivel Bracket Assembly) to #1 (Blade Assembly) with (8) 5/16” Hex
Bolts and Lock Washers.
3. Secure #3 (Swivel Yoke) to #4 (Swivel Bracket Assembly) using #5 (Large Washer)
and #8 (3/4” Nylock Nut).
4. Use #7 (4” Bent Hitch Pin) at Pivot Location
5. Use #6 (3” Bent Hitch Pin) to secure Rear Blade to Accessory Tool Bar Location.
For additional assistance, please contact our customer service department at (877)-9KOLPIN or
.
Kolpin Powersports, Inc.
205 N Depot Street
Fox Lake, WI 53933
Phone: 920-928-3118
Web: www.kolpinpowersports.com
