X10 resume dim Supported (by setting local on-level to zero)
X10 minimum transmit level 3.2 Vpp into 5 Ohms
X10 minimum receive level 20mV into 5 Ohms
X10 messages repeated No
Mechanical
Mounting
AC outlet
Wires
NA
Screw clamp connections NA
Case color White
Set button 1
Plastic UV stabilized polycarbonate
Beeper Yes
LED 1, RGB
Dimensions
10cm H x 4.3cm W x 3.4cm D – France
10cm H x 4.3cm W x 3.4cm D - Germany
10.4cm H x 5cm W x 3.5cm D – UK
10cm H x 4.3cm W x 3.4cm D - Chile
10.8cm H x 4.3cm W x 3.5cm D - AUS/NZ
Weight 130g ±10g
Operating environment Indoors
Operating temperature range 0
o
to 40
o
C / 32
o
to 104
o
F
Operating humidity range 0-90% relative humidity
Storage temperature range -20
o
to 70
o
C / -4
o
to 158
o
F
Electrical
Voltage 100VAC to 240VAC
Frequency 50/60Hz auto detected at power-up
Maximum load
300W (@ 240VAC)
300W (@ 120VAC)
Minimum load 5 Watts
Load type(s)
Lighting: Incandescent, dimmable CFL, dimmable halogen,
select dimmable LED*
*compatible with LED bulbs that support leading edge triac
dimming.
Hardwired remote control N/A
Retains all settings without power Yes, saved in non-volatile EEPROM
Standby power consumption < 0.75 watts
Safety approved CE, C-Tick
Certifications
EN 300 220-2, 301 489-3
AS/NZS 4268, CISPR 22
IEC 60669-2-1
