About keypad dimmer, Features and benefits – INSTEON Keypad Dimmer (Dual-Band) (2334-2xx US) Manual User Manual
Page 3

Page 3 of 24 Rev: 7/25/2013 9:16 AM
About Keypad Dimmer
Congratulations on your purchase of the elegant, high quality Keypad Dimmer. This in-wall switch with a built-in
dimmer can control up to 5 or 8 INSTEON/X10 scenes. Additionally, each button has an LED that can be easily
configured as a status indicator for virtually any INSTEON device/scene you wish to monitor. Finally, it comes
equipped with INSTEON’s patented dual-band communication technology for the most simple, reliable, brilliant
remote control available.
Features and Benefits
-
Integrated dimmer featuring 32 dim levels and 32 ramp rates
-
Wires in behind existing wall switch or in fixture box (requires neutral wire)
-
Can contain up to 400 controller/responder links
-
X10 compatible
-
All settings preserved in non-volatile memory, even through power failures
-
Beeper for easy setup assistance
-
Local programming lockout available via software
-
2-year warranty
