Page 12 of 24 Rev: 7/25/2013 9:16 AM

B’s scene controller LED will blink and Set button LED will blink green

5)

Press and hold Switch A’s Set button until it double-beeps (or LED flashes)

A will double-beep and its scene controller button and Set button LED will flash

B will double-beep and its LEDs will stop blinking

6)

Test the group by controlling the load from A and then B

The load and A’s and B’s scene controller button LEDs will all remain in sync

Example: Scene with any number of “N” members

We recommend using home-management software such as HouseLinc to create multi-member synchronized
scenes. However, the following steps, when carefully followed, will also work.

1) Turn all switches/dimmers on to the desired (and same) scene level

2) For each switch “X” where X goes from A through N:

a. Press and hold Switch X Set button until it beeps (or LED blinks)

Switch X’s LED will blink

b. Tap Switch X Set button

Switch X LED will continue blinking

c. For every other switch in scene, press and hold the Set button until it double-beeps and/or its LED

flashes

Switch will double-beep and its LED will flash once

d. Tap Switch X’s Set button

Switch X LED will beep and its LED will stop blinking

3) Test the group by controlling the load from each switch

The load(s) and all switches will remain in synch

Controlling the Keypad Load from Another Button on the Same Keypad

Have a button on the keypad control the load as part of a scene.

1) Press and hold the scene control button until it beeps

Keypad’s scene button LED will blink and Set button LED will blink green.

2) Press and hold the responder keypad button until it beeps

Keypad’s scene button and Set button LEDs will stop blinking

3) Confirm that the scene addition was successful by tapping the controller’s scene button a couple of times

Both the controller button and Main or On/Off button will turn on and off together

Changing Button Modes (Toggle/Non-Toggle Mode)

You can change any button to any one of 3 button modes (we recommend using home-management software such as
HouseLinc):

Toggle – toggles between on and off commands each time it is tapped
Always On – sends on every time it is tapped


Note: You cannot change the dedicated ON and OFF buttons in 6-button configuration.
