7.14 Net address
NET address
Disabled
Ю Я
1) On the Master card.
From the Calibration Menu, select
“NET address” and press ENTER. 2) Select “Master” and press ENTER
to confirm the calibration.
RSE card
The “NET address” function is set when connecting two paired operators.
Connect the two cards using the (2-A-B) terminals and insert the RSE cards into both.
On the “MASTER” card you have selected, make all of the required electrical connections and set the functions and adjustments
(see specific paragraphs).
If the system is fitted with sensitive edges on both gate leaves, carry out the electrical connections on (C7/C8) also for the “S
LAVE”
card.
In the event that the “Maintained action” function is activated, set it to (ON) on both of the cards and deactivate (OFF) the “Auto-
matic Closing” function on both.
If you wish to activate the “Automatic Closing” function, select is on both of the cards.
RSE card
NET address
Disabled Ю Я
NET address
Master Ю Я
3) Select “Slave” for another card.
NET address
Disabled Ю Я
NET address
Slave Ю Я
