4.1 Operator
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
2 Conditions of use
The BX10 operator is designed to power sliding gates in residential and condominium settings.
Do not install or use unless as otherwise shown in this manual.
3 Reference standards
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL OR QUALIFIED INSTALLERS”
2.2 Limitations to use
This product is engineered and manufactured by CAME CANCELLI AUTOMATICI S.p.A. in compliance with current safety standards.
Guaranteed 24 months if not tampered with.
The operator is made of a cast aluminium part inside of which operates the irreversible, electromechanical gearmotor and an ABS
plastic lining which holds the electronic card and transformer
4.2 Technical features
The company CAME cancelli automatici is ISO 9001:2000 quality certified; it has also obtained the ISO 14001 environmental safe-
guarding certification. CAME engineers and manufactures all of its products in Italy.
This product complies with the following legislation: see declaration of compliance.
For intensive or condominium use: max gate weight 800 kg with max gate length 20 m.
BX-10 OPERATOR
Control panel power supply: 230V A.C. 50/60Hz
Operator power supply: 230V A.C.
Draw: 2.4A
Power: 300 W
Reduction ratio: 1/33
Thrust: 800 N
Max speed.: 10 m/min max.
Duty cycle: 30%
Protection rating: IP54
Insulation class: I
Motor’s thermo-protection: 150°
Weight: 15 kg
—#
—#
