ST100 Series Configuration Software
Fluid Components International LLC 11
Diagnostics Tab Screens
Select the Diagnostics branch on the menu tree. The Diagnostics branch, Status Tab is shown below. A horizontal Tab structure across the top of
the screen is used when any of the main branch menus are selected.
Status
The Diagnostics branch offers 3 Tab selections
Tab Name Tab Description Password Level
Status Indicates System Status and Fault Flags Read only
Memory Factory Reserved Area (Not Shown) Factory
Scheduled Tests Enable/Disable Automatic Delta R test – Results logged to SD Card User
[User password 2772]
Scheduled Tasks
