7
Technical data
Type 8045
1. Measured value and type of the device
2. Specification of the flow sensor
3. Specification of the DO1 digital output
4. Specifications of the relay outputs DO2 and DO3
5. Electrical power supply and current consumption
6. Manufacturing code
7. Conformity logo
8. Warning: Before using the device, take into account the tech-
nical specifications described in these operating instructions.
9. Fluid temperature range and fluid nominal pressure
10. Protection class of the device
11. Specification of the DI1 digital input
12. Serial number
13. Order code
14. Shows the flow direction
Fig. 1: Name plate of the 8045 flowmeter
6. TechnicAl DATA
6.1. conditions of use
Ambient temperature -10 to +60 °C
Air humidity < 85%, non condensated
Height above see level max. 2000 m
Protection class acc.
to EN 60529
IP65, device wired and cable glands
tightened and cover lid screwed tight.
6.2. conformity to standards and
directives
The device conforms to the EC directives through the following
standards:
• EMC: EN 61000-6-2, EN 61000-6-3
• LVD: EN 61 010-1
• Vibration: EN 60068-2-6
• Shock: EN 60068-2-27
Pressure: article 3§3 of the Pressure Directive 97/23/CE. Acc. to
the Pressure Directive 97/23/CE: the device can only be used in the
following cases (depending on the max. pressure, the DN of the pipe
and the fluid)
type of fluid conditions
Fluid group 1, par. 1.3.a Forbidden
