Nstallation – Burkert Type 8750 User Manual
Page 39

I
NSTALLATION
8750 - 37
Vorkonfektionierte Kabel als Zubehör
Kabel mit M16-Buchse:
Bestell-Nr. 651652: Kabel 2 m mit M16-Buchse, 12-polig
Bestell-Nr. 651653: Kabel 5 m mit M16-Buchse, 12-polig
PIN
Signal
Litzen-Farbe
A
Sollwert GND
weiß
B
Sollwert + (0/4..20 mA oder 0..5/10 V)
braun
C
Analoge Stellungsrückmeldung +
grün
D
Analoge Stellungsrückmeldung GND
gelb
E
Binärer Ausgang 1
grau
F
Binärer Ausgang 2
rosa
G
Binärer Ausgang GND
blau
H
Binärer Eingang +
rot
J
Binärer Eingang GND
schwarz
K, L, M
nicht belegt
nicht belegt
Alle Litzen sind mit Aderendhülsen versehen.
Kabel mit M12-Buchse:
Bestell-Nr. 918038: Kabel 5 m mit M12-Buchse, 4-polig
PIN
Signal
Litzen-Farbe
1
+ 24 V
braun
2
nicht belegt
weiß
3
GND
blau
4
nicht belegt
schwarz
Alle Litzen sind mit Aderendhülsen versehen.
