Nstallation – Burkert Type 8750 User Manual
Page 13

I
NSTALLATION
8750 - 11
Prefabricated cables as accessories
Cable with M16 socket:
Order no. 651652: 2 m cable with M16 socket, 12-pin
Order no. 651653: 5 m cable with M16 socket, 12-pin
PIN
Signal
Wire colour
A
Nominal value GND
white
B
Nominal value + (0/4–20 mA or 0–5/10 V)
brown
C
Analogue position feedback +
green
D
Analogue position feedback GND
yellow
E
Binary output 1
grey
F
Binary output 2
pink
G
Binary output GND
blue
H
Binary input +
red
J
Binary input GND
black
K, L, M
not used
not used
All wires feature wire end ferrules.
Cable with M12 socket:
Order no. 918038: 5 m cable with M12 socket, 4-pin
PIN
Signal
Wire colour
1
+24 V
Brown
2
Not used
White
3
GND
Blue
4
Not used
Black
All wires feature wire end ferrules.
