Specifications and Dimensions
F8112101 36
Table 13
Model 125 Pound 140 Pound 175 Pound
H-Series H-Series H-Series
A
4 in.
(102 mm)
4.63 in.
(118 mm)
4.63 in.
(118 mm)
B
1.5 in.
(38 mm)
1.5 in.
(38 mm)
1.5 in.
(38 mm)
C
7 in.
(178 mm)
7 in.
(178 mm)
7 in.
(178 mm)
D
47.5 in.
(1207 mm)
49 in.
(1245 mm)
54 in.
(1372 mm)
E
27 in.
(686 mm)
27 in.
(686 mm)
27 in.
(686 mm)
F
18 in.
(457 mm)
18 in.
(457 mm)
18 in.
(457 mm)
G
9 in.
(229 mm)
9 in.
(229 mm)
9 in.
(229 mm)
H
3.5 in.
(89 mm)
4.88 in.
(124 mm)
4.88 in.
(124 mm)
I
48.1 in.
(1221 mm)
48.1 in.
(1222 mm)
48.1 in.
(1222 mm)
J
37.35 in.
(949 mm)
37.35 in.
(949 mm)
37.35 in.
(949 mm)
K
50.56 in.
(1284 mm)
50.56 in.
(1284 mm)
50.56 in.
(1284 mm)
L
40.47 in.
(1028 mm)
40.47 in.
(1028 mm)
40.47 in.
(1028 mm)
M
45.2 in.
(1148 mm)
45.2 in.
(1148 mm)
45.2 in.
(1148 mm)
N
54.42 in.
(1382 mm)
54.42 in.
(1382 mm)
50.42 in.
(1281 mm)
O
67 in.
(1702 mm)
68.07 in.
(1729 mm)
71.75 in.
(1822 mm)
P
59.75 in.
(1518 mm)
60.95 in.
(1548 mm)
65.04 in.
(1652 mm)
Q
36.25 in.
(921 mm)
36.25 in.
(921 mm)
36.25 in.
(921 mm)
R
47.25 in.
(1200 mm)
47.25 in.
(1200 mm)
47.25 in.
(1200 mm)
S
50.25 in.
(1276 mm)
50.25 in.
(1276 mm)
50.25 in.
(1276 mm)
