Specifications and Dimensions
F8112101 12
Table 1 (continued)
Models
Specifications 40H 60H 80H 100H 125H 140H 175H
Water Inlet
Connection Size 3/4 NPT 3/4 NPT 3/4 NPT 3/4 NPT 3/4 NPT 1-1/4 NPT 1-1/4 NPT
Number of Inlets,
(std/opt) 2/3 2/3 2/3 2/3 2/3 2/3 2/3
Chemical Supply System
Number of Dry
Chemical
Compartments,
(std/opt) 1/5 1/5 1/5 1/5 1/5 1/5 1/5
Number of Liquid
Supply Connections,
(std/opt) 6/12 6/12 6/12 6/12 6/12 6/12 6/12
Cylinder Speeds/Centrifugal Force Data
Possible Wash Speeds,
RPM (G-Force) 10-60
(0.05-1.4)
10-60
(0.04-1.6)
10-60
(0.05-1.9)
10-60
(0.05-1.9)
10-55
(0.06-1.9)
10-55
(0.06-1.9)
10-55
(0.06-1.9)
Preset Wash Speed,
RPM (G-Force) 46
(0.8)
43
(0.8)
39
(0.8)
39
(0.8)
36
(0.8)
36
(0.8)
36
(0.8)
Balance Speed,
RPM (G-Force) 81
(2.5)
75
(2.5)
69
(2.5)
69
(2.5)
69
(2.5)
64
(2.5)
64
(2.5)
Preset Low Extract
Speed, RPM (G-Force) 511
(100)
477
(100)
437
(100)
437
(100)
405
(100)
405
(100)
405
(100)
Preset Medium Extract
Speed, RPM (G-Force) 605
(140)
564
(140)
516
(140)
516
(140)
479
(140)
479
(140)
479
(140)
Preset High Extract
Speed, RPM (G-Force) 775
(230)
723
(230)
662
(230)
662
(230)
573
(200)
573
(200)
573
(200)
Maximum SmartSpin
Speed, RPM (G-Force) 885
(300)
826
(300)
756
(300)
756
(300)
701
(300)
640
(250)
640
(250)
Drive Train Information
Number of Motors In
Drive Train 1 1 1 1 1 1 1
Drive Motor Power,
hp (kW) 3
(2.3)
5
(3.7)
7.5
(5.6)
7.5
(5.6)
10
(7.5)
7.5
(5.6)
15
(11.2)
Balance Detection
Vibration Switch
Installed STD STD STD STD STD STD STD
Electrical Heating (Optional)
Total Electrical Heating
Capacity, kW 21.5@240V
21.5@480V 32.2@240V
21.5@480V 32.2@240V
21.5@480V 32.2@240V
21.5@480V Not
Applicable
Not
Applicable
Not
Applicable
Number of Electrical
Heating Elements 6 – 240V
6 – 480V 9 – 240V
6 – 480V 9 – 240V
6 – 480V 9 – 240V
6 – 480V Not
Applicable
Not
Applicable
Not
Applicable
Electrical Heating
Element Size, kW 3 3 3 3 Not
Applicable
Not
Applicable
Not
Applicable
Table 1
All specifications are subject to change without notification.
