- - 6
CONNECT THE AC ADAPTER
1. Remove the PCMCIA interface card from your computer.
2. Connect the AC adapter plug to the DC-IN jack at the CD-ROM rear panel.
3. Attach the AC adapter to the AC outlet.
CAUTION
Use only the AC adapter provided with this unit or refer to the rear panel
of the drive for the correct AC adapter. Using the incorrect AC adapter
will cause permanent and unpredictable damage to the CD-ROM.
INSTALL THE BATTERIES
The CD-ROM requires six AA size batteries (not included) for operation. The
Alkaline batteries may last longer than other batteries. You may also use Ni-Cad
rechargeable batteries which have a shorter service life. Neither the rechargeable
battery nor the charger are provided with this package.
Follow the instruction below to install the batteries,
1. Remove the disc from the CD-ROM.
2. Disconnect the PCMCIA interface card
from your computer, and disconnect the AC
adapter from the “DC-IN” jack.
3. Turn over the CD-ROM drive and place it
horizontally.
4. Press and slide the battery lid in the
direction of the arrow to remove it.
5. Install six fresh AA batteries (as shown in
Figure 5), and make sure the polarities
match the diagram.
6. Replace the battery lid.
Figure 5
