450564 - 3 www.amdry.com 7
Dual Timer Control Door Assembly
For Models Mfd. prior to July 11, 2002
Illus. No. Part No. Qty. Description
1 ––––––* 1 Logo ONLY
2 881869 1 White Control Door Assembly
(for models mfd. as of October 24, 1997)
(includes illus. nos. 2, 3, and 8)
881744 1 White Control Door Assembly
(for models mfd. prior to October 24, 1997)
(includes illus. nos. 2, 3, and 8)
3 117604 4 Noise Suppression Tape (sold by the foot)
4 150309 4 #10-16 x 1/2” Hex Head TEK Crimptite Screw
5 102603 1 Control Door Rod Support Catch
6 102601 1 Control Door Rod Retainer Clip
7 102502 1 Control Door Support Rod
8 882541 2 Spring Turn Latch (2-piece)
* Contact reseller for logo.
