18 American Dryer Corporation 450564 - 3
Lint Trap Assembly
Illus. No. Part No. Qty. Description
1 800402 1 Non-Reversing Lint Trap Assembly Complete
(includes illus. nos. 1 and 3 through 5)
800404 1 Non-Reversing Lint Trap ONLY
800407 1 Reversing Lint Trap Assembly Complete
(includes illus. nos. 1 and 3 through 5)
800406 1 Reversing Lint Trap ONLY
2 154200 7 5/32” Pop Rivet
3 304101 1 Lint Screen Holder ONLY
4 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
5 800501 1 Lint Screen ONLY
6 150419 2 #6 x 1/2” Tamperproof TEK Screw
7 108120 1 Chain for Drop Lint Door (10-1/2” length)
8 150425 2 #12-24 x 3/8” Phillips Round Head Machine Screw
9 122116 1 Lint Drawer Switch ONLY
10 323724 1 Lint Drawer Switch Bracket Assembly
