46

American Dryer Corporation

450564 - 3

Illus. No.

Part No.

Qty.

Description

1

165114

1

Fire Suppression System Solenoid Valve 24V 50/60 Hz

2

143220

1

3/8” F.P.T. Brass Tee

3

143251

1

3/8” M.P.T. Brass Plug

4

143208

2

3/8” Comp x 3/8” M.P.T. Brass Connector

5

143099

6’

3/8” OD x 0.035 Wall Copper Tubing (sold by the foot)

6

311588

1

Sprinkler Head Mounting Plate

7

143303

1

3/8” N.P.T. Brass Locknut

8

143155

1

3/8” Brass Elbow 90°

9

150430

2

#10 x 1/2” Self-Drilling Screw

10

150301

2

#8-18 x 7/16” Phillips Pan Head TEK Screw

11

143581

1

3 GPM 3/8” F.P.T. Spray Nozzle

12

142888

1

1/2” to 3/8” Bushing for Fire Suppression System Valve

13

824828

1

Arc Suppressor

F.S.S. Solenoid Assembly
