Electric Oven Component
Application Chart
kW
Voltage
Phase
Wire
Oven
Assembly
*
Part No.
Element
Oven Wire
with Crimp Terminal
Terminal Lug
Bus Bar
Part No.
121011
Oven Relay
Qty.
kW
Part No.
Qty.
Size
Part No.
Qty.
Part No.
Cat. No.
Part No.
30
480
3Ø
3
826222
6
5
120013
1
#8
882572
1
121010
1
DPA43
131357
30
240
3Ø
3
833124
6
5
120013
1
#4
882566
1
121010
1
DPA73
131376
