450564 - 3 www.amdry.com 15
Drop Lint Door Assembly
Illus. No. Part No. Qty. Description
1 800150 1 Knob Latch Kit Assembly
(includes illus. nos. 1 through 3)
2 160009 1 Knob Latch Adjustable Cam ONLY
3 150425 1 #12-24 x 3/8” Round Head Machine Screw ONLY
(screw for knob latch adjustable cam)
4 157000 1 Drop Lint Door Spring
5* 881870 1 White Drop Lint Door Assembly
(includes illus. nos. 5 and 6)
6 117604 7 Noise Suppressor Tape (sold by the foot)
7 150419 2 #6 x 1/2” Tamperproof TEK Screw
8 108120 1 Chain for Drop Lint Door (10-1/2” length)
* Specify color when ordering.
